I.Main performance and structure features
1.Dual frequency conversion control, bag length can be set and cut in one step,saving time and film.
2.Interface features easy and quick setting and operation.
3.Self failure diagnosis,clear failure display.
4.High sensitivity photoelectric eye color tracing, numerical input of cutting sealing position for extra accuracy.
5.Temperature independent PID control,more suitable for packaging different materials.
6.Positioned stop function,without sticking knife or wasting film.
7.Simple driving system,reliable working,convenient maintenance.
8.All control is realized through computer program,easy for function adjusting and technical upgrade.
II.Application
Suitable for packing regular objects such as biscuit,bread,instant noodle,moon cakes,industrial parts,paper box or trays.
III.Optional device
1.Code applying machine
2.line sealing wheel
3.Moire terminal sealing mould
4.Extra big screen
Specification:

Model	ZSJ-280	ZSJ-320	ZSJ-350	ZSJ-420	ZSJ500	ZSJ-600
Material	Painted & Touch S.S 304		Painted & Touch S.S 304	Painted & Touch S.S 304		Painted & Touch S.S 304
Packing speed	10-180 bag/min				10-150 bag/min
Packing size(mm)	L60-280   W10-40/40-80  H 5-25/25-40	L60-320   W10-40/40-100 H5-30/30-60	L80-320   W30-100  H5-50	L80-320   W30-140	L80-350   W30-180  H5-70	L120-999   W30-220  H5-100
				H5-60
Max width of film	280mm	320mm	350mm	420mm	500mm	600mm
Tickness of  film	≥0.02mm
Total  power	2.5KW	2.5KW	3.0KW	3.0KW	3.0KW	3.0KW
Voltage	220V-380V  50Hz
Packing material	OPP/PP OPP/CPP PT/PE PE KOP/CPP PT/PE AL/PE etc.
Dimension	4790*700*1520mm	4790*700*1520mm	4700*800*1550mm	4700*880*1550mm	5320*1020*1520mm	5320*1020*1520mm
Package	500kg	580kg	500kg	500kg	600kg	900kg
