Product Description:
The machine is mainly applicable to collection pack "standard" and "mini" handkerchief paper, also applies to
tridimensional transparent film pack other corresponding vierkante size items. This machine with compact structure,
attractive appearance, simple operation, easy maintenance, high degree of automation advantage, with moisture
protection, durability, improve product quality function. This is an ideal automatic handkerchiefs packaging equipment.
Main features:
1. This machine is suitable for packing standard and mini-handkerchief
2. This machine equiped with automatic manage and feed mechanism, it can automatic connect with handkerchiefs
production line to be a fully automatic packaging production line, parallel stacking device can stack 1to3 layer according
to the requirements of customer.
3. Using multifunctional digital frequency adjustment, PLC programmable control system to make the control more
advanced and easier to adjust and maintain;
4. Touchscreen operation interface make humanmachine conversation more friendly, the parameter setting is more
convenient and faster;
5. No film automatic alarm, fault alarm display makes operation and maintenance more convenient and faster.
6. There are fixed length and label following two methods for controlling pull film length.
7.The electrical components adopt international famous brand, quality is more stable and reliable;
8. Vacuum film feeding system to send film more smoothly, working more stable;
9. Can be equiped with printing devices according to customer's requirements;
10. Specifications changed fast and convenient
specification
Item
|
Data
|
Capacity
|
10-25bags/min
|
· number of pliers
|
1-3 pliers
|
Packing place
|
2*3、2*4*、2*5、2*6、3*3、3*4、3*5、3*6
|
Packing range
|
L:50-320 W:40-170 H:20-90
|
Voltage
|
380V 50HZ
|
Driving motor power
|
0.75KW
|
Heating power
|
3KW
|
Air compressor
|
0.6MPa
|
Conveyoe
|
(0.18+0.15)KW
|
Packing material
|
CPP\OPP the thickness of two sides heating film 0.035-0.05mm
|
Machine size(L*W*H)
|
2200*950*1850mm
|
Machine weight
|
1400kg
|
Conveyor system weight
|
300kg
|
