Summary：
Washer, Filler and Capper 3-in-1 Machine is mainly used in the beverage filling operations. The three functions of washing, filling and capping are
composed in one body of the machine. The machine is used in filling water drink in PET bottles. The operation of
the machine can be freely and conveniently turned to adjust the machine to fill various types of bottles. The filling
operation is faster and more stable. This machine is suitable for pure water, mineral water, and other liquid with
normal temperature. Not suitable for juice, tea drinks in high temperature hot filling condition.
Specification:
|
Washing position
|
12
|
Bottle diameter
|
φ50-φ110mm
|
|
Filling position
|
12
|
Bottle height
|
160mm-300mm
|
|
Capping position
|
5
|
Capacity
|
|
|
Main motor power
|
3KW
|
500ml
|
4500B/H
|
|
Capping power
|
0.37KW
|
750ml
|
3500B/H
|
|
Washing power
|
0.55KW
|
1000ml
|
2500B/H
|
|
Filling power
|
0.75KW
|
1500ml
|
1500B/H
|
|
Conveyor power
|
0.55KW
|
2000ml
|
1000B/H
|
|
Air flue power
|
2.2KW
|
2250ml
|
800B/H
|
|
Machine weight
|
3000KG
|
Machine size
|
2400×1640×2520
|
