Product name : DYGS Courier Bags series

Item : DYGS

Enlarge Image

Back

Details:

Machine introduced

DGS Courier Bags IS OUR NEW DEVELOPED MODEL,IT USE INSTANT DYNAMIC WEIGHING MONITOR TECHNOLOGY,FULLY INTELLIGENTIZED THE QUANTITATIVE FILLING.ON-LINE SUPERVISE EVERY QUANTITATIVE WEIGHING PROCESS.AUTO-RECTIFY THE ERROR WHEN FILLING AUTO-ORIENTATION & NUMERATION THE PACKES THIS MODEL MAKES THE FILLING PROCESS TO BE FULLY AUTOMATICALLY FILLS THE BLANK OF THIS FIELD.

Applicability

1.Solid Species candy,peanut,green bean,pistachio,crystal candy,brown sugar,cookie,cake,daily commodities,cooked food,pickies,puffed food etc.
2.Granule Species grain,refined monosodlum glutamate,granular drug.capsule,seed,chemistiy condiment,granulated sugar,chicken essence,melon seed,nuts,pesticide,fertilizer,feed etc.
3.Powder species milk powder,grape sugar,washing powder,chemistry condiment,refined sugar,pesticide,fertilizer etc.

Features & Characteristics

1.High precision digital weighing transducer to realize precise metering moments.
2.Use independent property microcomputer control system,adopt double vibrates the feeding,deserve to touch human-machine interface control system,easy operation.
3.Product or packing bag contact parts adopt stainless steel or other materials which accord with the food hygienic requirements,guarantee hygiene and security of the food.
4.Measuring dou can quickly remove,easy cleaning maintenance.
5.According to user requirements,different forms of combination packing,expanding heavy range.
6.It use real-time dynamic weighing monitoring technology,complete intelligent filling the quantitative.Supervise every online quantitative weighing process.When weighing appear when automatic on-line correcting error.
7.Tanks automatic counting positioning,and various auxiliary combination(such as:automatically unscramble cans machine,automatic capping machine etc)composition filling automatic production line.

Specifications and paremeter

Model No.	DYGS-AX1	DYGS-AX2	DYGS-AX4	DYGS-AX6
Filling Capacity	50-3000g	50-3000g	50-3000g	50-3000g
Production capacity(cans/min)	10-14	15-18	20-26	25-32
Filling Accuracy	≤2kgs : ±2g ; ≤2kgs : ±2g ;	≤2kgs : ±2g ; ≤2kgs : ±2g ;	≤2kgs : ±2g ; ≤2kgs : ±2g ;	≤2kgs : ±2g ; ≤2kgs : ±2g ;
Conveyor Belt length(meter)	2	2	3.2	3.2
Power supply	200W	220W	280W	320W
Machinery weight	200KGS	300KGS	600KGS	800KGS
Dimension(LWH)mm	200013001750	200013001850	320015002200	320015002400
Compress Air Requirment	0.4m³/min	0.4m³/min	0.4m³/min	0.4m³/min
